This series of equipment is used for the production of still beverages such as purified water, fruit juice, and energy drinks.
This Small bottle water filling machine is a three-in-one machine for washing, filling and capping, suitable for various bottle types. Adopt suspended wind conveyor. When changing bottles, you only need to adjust the conveying width, which is more efficient and labor-saving. This machine adopts normal pressure filling type, which is faster and more stable. This Rotary bottle filling machine adopts advanced PLC programming control system, and the electrical components adopt international famous brands. The design of the whole machine is scientific and reasonable, with high output and low failure rate.
FEATURES DESCRIPTION:
1) The pneumatic conveyor is directly connected with the imported star wheel, instead of the screw and the conveying chain, it is more convenient to change the bottle.
2) Bottleneck consignment does not need to adjust the height of the equipment, only some spare parts need to be replaced.
3) The high-speed filling line adopts the clamp transmission technology, the bottle types are more diverse, and the working table inside the machine is more concise.
4) Washing Filling Capping Monoblock, less wear in bottle rinsing, filling and capping, stable conveying and easier bottle changing.
5) The specially designed stainless steel bottle clamp does not touch the threaded part of the bottle neck to avoid secondary pollution.
6) High-speed and large-flow filling valve ensures fast filling speed and accurate liquid level.
7) The parts in contact with the liquid are made of high-quality stainless steel or food-grade plastic. The electrical system adopts international brands and meets the national food hygiene standards.
8) The star wheel for bottle discharge is screw-in type. When changing the bottle type, there is no need to adjust the height of the conveyor chain.
FLOW CHART:
A) Bottle production line: PET resin-injection molding machine-blowing machine-PET bottle
B) Water treatment system: raw water -- water pump -- silica sand filter -- carbon filter -- water softener -- reverse osmosis -- ultraviolet sterilizer -- ozone generator -- finished water tank
C) Filling & packaging part: bottle unscrambler--air delivery-- Automatic 3 in 1 PET bottle filling machine--light inspection--drying machine--laser inkjet printer--labeling machine-- Packing machine – storage
TECHNICAL PARAMETER:
|
Model |
CGF8-8-3 |
|
Number of flushing heads |
8 |
|
Number of filling heads |
8 |
|
Number of capping heads |
3 |
|
Production capacity |
2000-3000BPH(500ML) |
|
Main motor power |
1.5kw |
|
Dimensions (mm) |
1900*1350*2200 |
SERVICES:
1. Tested and inspected in our workshop before delivery.
2. After one year of warranty, we will provide accessories with factory price.
3. Free spare parts: related vulnerable parts.
4. Provide technical guidance and process configuration teaching.
5. Assist in the design of product lines, factory buildings and provide turnkey projects.
6. Warranty period: one year from the date of installation or acceptance of the equipment, whichever comes first
FAQ:
Q: What's the guarantee or quality guarantee for the machine?
A: To provide you with high quality machines, the warranty period is 1 year. We will provide you spare parts for free within 1 year.
If during the warranty period, the quality or specifications of the goods are found to be inconsistent with the contract requirements, or the goods are found to be defective (including latent defects or the use of substandard materials, etc.), the buyer has the right to contact the relevant statutory agency to issue inspection documents for compensation. During the warranty period of the goods, the buyer can file a claim against the seller, and the seller will compensate the customer for the loss according to the relevant requirements.
Q: What's the delivery time?
A: 15-90 days after T/T deposit or L/C. (The premise is to receive samples and deposit from customers).
Q: How about the product material and configuration used?
A: 304 stainless steel, frame material is steel. The equipment can be made of 316 stainless steel, the whole machine can be made of stainless steel according to the customer's customized requirements, and the electrical components can be configured according to the specified brand according to the customer's needs.
